HA5800/O

HA5800/O is a carrier-grade outdoor 1550nm EDFA designed for FTTH Video Overlay, RFoG and next-generation GPON/XGS-PON access networks.

Featuring a Dual-Stage Amplification Architecture combining ultra-low-noise EDFA pre-amplification and high-power EYDFA booster amplification, the HA5800/O delivers output power up to 37dBm with noise figure ≤5.5dB.

Built-in CWDM technology enables simultaneous transmission of 1550nm video services and PON data signals over a single fiber, reducing fiber usage and simplifying network deployment.

Its IP65 aluminum enclosure, passive cooling structure, anti-corrosion design and anti-RF interference protection ensure reliable long-term outdoor operation.

◉ Dual-Stage EDFA + EYDFA Amplification Architecture
◉ Built-in CWDM Multiplexing Technology
◉ Compatible with GPON, EPON, XG-PON and XGS-PON
◉ Total Output Power up to 37dBm (5000mW)
◉ Ultra-Low Noise Figure ≤5.5dB
◉ Up to 16 Optical Outputs with Integrated PON Uplink Ports
◉ Optional Dual Optical Input Protection Switching
◉ Optional 1+1 Redundant Power Supply
◉ SNMP Remote Management Support
◉ Carrier-Grade Reliability
◉ IP65 Weatherproof Aluminum Housing
◉ Anti-RF Interference Protection
◉ Anti-Corrosion Design
◉ Fanless Passive Cooling
◉ Pole, Wall and Outdoor Cabinet Installation
◉ Built-in Lightning and Surge Protection
◉ No Equipment Room Required
◉ Lower OPEX and Simplified Network Architecture
