GDS-6800

GDS-6804 series micro-wave Direct Modulated Optical Transmitter, the working broadband is 47~862MHz & 950~6000MHz. By internal frequency overlay, can transmit 4 SAT-IF, 4 roads sat TV signals and CATV signal of 47~862MHz with high quality by one fiber.

It can supply high quality of satellite live TV service that come from maximum 4 satellites & CATV service for many users by FTTH, FTTB.

GDS-6800 working wavelength is optional 1310nm or 1550nm. Choose 1550nm working wavelength can use EDFA & EYDFA to realize large area coverage. It is compatible with any FTTx PONtechnology. Realize multi-way satellite TV, internet integration of three networks.

SAT-IF input signal of GDS-6800 can come from 4 different satellites, and also can come from one satellite’s 4 SAT-IF signal. If adopt one satellite’s 4 SAT-IF, can adopt Quattro LNB 4 SAI-IF output tuner, such as our LNB2204.

GDS-6800 adopts high linearity broadband and microwave direct Modulated DFB laser. Excellent laser APC, ATC control, perfectRS232 interface. High performance, high flexibility, high reliability and excellent performance price ratio. It is the ideal choice for subscribers.



◉ FTTH, FTTB(CATV & 4 SAT-TV)

◉ Triple-play(CATV, 4SAT-TV & Intranet)
