GT LASERS H1228, the operating bandwidth of 47~ 1200MHz,it is a low power, high performance, cost-effective triple play, FTTH CATV optical receiver, Whether used in analog television or digital television. Products with high sensitivity optical receiver tube and Huatai special low noise matching circuit. Receiving at high optical power can be adjusted by PAD level, played limiting output, so H1228 within a large dynamic range of the received optical power of +2 dBm ~-21dBm, have excellent characteristics.
H1228 for Analog TV, in Pin =-10dBm when, Vo≥ 75.7dBμV, CNR≥ 45.3dB.
H1228 for Digital TV, in Pin =-16dBm when, Vo≥ 67.2dBμV, MER≥ 36.1dB.
H1228 for Digital TV, in Pin =-20dBm when, Vo≥ 58.8dBμV, MER≥ 30dB.
Triple play, fiber to the home, using theH1228 can save a lot of optical fiber amplifier power resources. For operators, can greatly reduce the cost of building the network.:
H1228 optical port mode and form of the following three selection:
H1228 : CATV operating in 1260~1620nm wavelength. A-Type
H1228/WF: Build-in 1310/1490 filter, CATV operating wavelength 1550nm.A-Type
H1228/WD: Build-in CWDM，CATV operating wavelength 1550nm, pass wavelength 1310/1490nm, ( Link EPON、GPON ONU ).B-Type
