HA5200

GT LASERS HA5200 series C-Band line-amplifier EDFA (also knows as relay EDFA), is designed for the application of single channel or 1~8 continuous ribbon channels (ITU wavelength). Fiber CATV system operates generally in single wavelength that has no strict requirement on gain flatness. In order to reduce the effect of CNR deterioration caused by EDFA, input power should be as high as possible to make EDFA operate in saturated output power. The typical value of input power is >+3dBm.

HA5200 relay EDFA (Low-Input type) adopts noise filtration technology in the optic path, and can filter spontaneous radiation effectively. When the input is 0dBm, its CNR can reach 49.5dBm, applied in sub head-end and line relay.

GT LASERS is the famous manufacturer of EDFA. HA5200 adopts the world's top class pump laser and America OFS erbium-doped optical fiber. Perfect APC, ACC and ATC control, excellent design in the ventilation and heat-dissipation ensure the long life and high reliable work of pump laser. RS232 and RJ45 offer serial commutate ion and SNMP network management port. The LCD at the front panel offers the work index of all equipment and warning alarm. Optical loss and laser closing automatically provide safe protect of the laser. All the optical port can be installed in the front panel (also can be in the back panel if customers specify).

GT LASERS product, for its high quality, high reliable and high cost performance, is the ideal choice of the system integration and system operation.

◉ In the original 1550nm optical system, all 1310nm optical transmitters can be cancelled in the second grade service area with 0dBm receiving power. Instead, HA5200 can be adopted to carry out full optic relay and then achieve large acreage cover of all the service area.

◉ Over-long trunk with low-input

◉ AM CATV

◉ Digital CATV

◉ DBS & MMDS

◉ FTTx PON

◉ Laboratory application



Remark: Output power can be customized by user.
