MT60

MT60 series microwave DML optical transmitter, are able to transmit 33G microwave RF signal with long distance, wide bandwidth, and flat responsibility. They provide an outstanding linearity fiber optical communication for analogue and digital wideband microwave application. Due to avoidance of using expensive coaxial cable or wave guide, there will be no limitation in transmission distance, which improves the signal quality and reliability of the microwave communication. They can be widely applied in microwave communication system such as remote wireless; timing and reference signal distribution, telemetry, measurement and delay line etc as well as 10Gb/s and 60Gb/s high speed communication system.

MT60 adopts high linearity microwave Electro-Absorption (EA) Modulator with DFB Laser (EML). Full-transparency operation mode. Without RF Amplifier, Low cost, flexible application in networks.

MT60 series operation wavelength optional:

B type: 1310nm.

C type: C-Band, 1528~1565nm.

L type: L-Band, 1570~1605nm.

T type: ITU-T standard wavelength is adjustable. T type is suitable for DWDM system.

MT60 Four exterior structures available:

MX: module type, RS232 is an option, suitable for OEM, Exterior structure and size of the module as well as the PIN description can be specified by customers.

2D: desk top, with RS232 and LCD display, suitable for laboratory use.

1U, 3U: 19" casing, with RS232, SNMP, suitable for direct use in networks.

 Antenna Remoting

 Long distance analog fiber-optic communications

 Cellular and PCS networks

 Military triband communications

 Tracking, telemetry and control (TT&C)

 High speed lightwave characterization

 Delay lines

 Phased arrays

 Microwave electronics

 10Gb/s, 40Gb/s communication systems
