OPS-1000

OPS-1000 Optics Protection System product series, mainly applies to optical communication field of single fiber two-way for main, light path switching equipment. It makes up from light path switching unit, optical power monitoring unit and network management terminal. In optical communication networks, OPS-1000 real-time monitor the optical power of operating fibers and spare fibers, when monitor the optical light path’s optical power is lower than setting switching threshold, it will alarming prompt and switch to the spare fiber to realize the line protection of optical transmission system.

OPS-1000 with two light path protection modes:

1. OPS-1051 (1+1 protection mode): receiving port 2x1 optical switch; transmitting port 50/50 splitter, splitter can choose other splitting ratio: 60/40、70/30、80/20、90/10

2. OPS-1011(1:1 protection mode): receiving port 2x1 optical switch; transmitting port 2x1 optical switchch; transmitting port 50/50 splitter, splitter can choose other splitting ratio: 60/40、70/30、80/20、90/10

OPS-1000’s bi-direction operation wavelength can be appointed by user; there are three regular types as below:

1. OPS-1500：Bi-direction operation wavelength with 1528~1565nm C-Band;

2. OPS-1600：Bi-direction operation wavelength with C-Band & L-Band;

3. OPS-1400：Bi-direction operation wavelength with 1540~1610 & 1310/1490;

◉ Single fiber Two-way optical communication network protection and recover

◉ Network detection and switch



Remark: Input power optional B type (-23~+23dBm) and C type (-45~+23dBm)
