VOA500

GT LASERS VOA500 series assemble multi high-resolution electricity controlled optical attenuators into 1RU or 3D housing, mainly applied to optical adjustment and automatic equilibrium in DWDM system's and multi-channel network and optical amplify network.

VOA500 is a standard type product. Each attenuator with an attenuation value of monitoring. RS232 and RJ45 provide serial communication and SNMP network interface. LCD on the front panel provides every work parameter and fault alarm of the whole unit. All the optical port can install on the front panel or back panel.

◉ DWDM system, power adjustment and automatic equalization in multi-channel.

◉ Power control into narrowband wavelength division multiplexers (WDMs) and configurable networks.

◉ In Lab.

Performance			Index			Supplement
			Min.	Typ.	Max.
Optical feature	Operating wavelength range	(nm)	1200		1620
	Optimum operating wavelength range	(nm)	1525		1575
	Resolution	(dB)			0.1
	Minimum attenuation	(dB)		0.7	1.2
	Attenuation Range	(dB)	20			VOA520
			30			VOA530
			35			VOA535
			40			VOA540
			45			VOA545
	Attenuation setting accuracy	(dB)	-.0.2		+0.2
	Attenuation monitor accuracy	(dB)	-0.2		+0.2
	Tuning speed	(ms)		20
	Polarization mode dispersion	(ps)			0.1
	Polarization dependence gain	(dB)			0.2
	Polarization dependence loss	(dB)			0.3
	Wavelength dependence ripple	(dB)			0.2
	Temperature-related attenuation	(dB)			0.15
	Power handling	(mW)			500
	Return loss	(dB)	-50			PC
	Power attenuation state (with unit powered off)		Keep        ATT/Keep			K grade
			Open        ATT/Min			O grade
			Closed       ATT≥40dB			C grade
General feature	SNMP network management interface		RJ45
	Series interface		RS232
	Power supply	(V)	90		265	220VAC
			30		72	-48VDC
	Power consume	(W)			50
	Operating temp.	(°C)	0		65
	Storage temp.	(°C)	-40		80
	Relative humidity	(%)	5		95
	Size (W)×(D)×(H)	(")	19×14.5×1.75			1RU (19”)
			19×11×1.75
			12.4×15.4×5.25			3D (12.4”, desk-type)
